> LSZH – low smoke zero halogen

> UV-resistant

> Longitudinaly and laterally water-resistant

> Glass yarn armoured

> Non-metal rodent protection

> Metal free

> Core diameter : 50.0 ± 2.5 μm

> Cladding diameter : 124.8 ± 1.0 μm

> Core-non-circularity : ≤ 5.0 %

> Cladding-non-circularity : ≤ 1.0 %

> Core-cladding concentricity error : ≤ 1.0 μm

> Coating diameter : 245 ± 7 μm

> Coating non-circularity : ≤ 6.0 %

> Cladding-coating concentricity error : ≤ 12.0 μm

> OFL bandwidth : at 850mm : ≥ 1500 MHz x km ; at 1300mm : ≥ 500 MHz x km

> Effective modal bandwidth : at 850mm : ≥ 2000 MHz x km ; at 1300mm : ≥ 500 MHz x km

> Attenuation coefficient : at 850nm : ≤ 2.3 dB/km ; at 1300nm : ≤ 0.6 dB/km

> Fiber count (OM3) : 2-12 pc

> Max. number of loose tube : 1 pc

> Fiber number per tube : 2 - 12 pc

> Loose tube : 2.0 ± 0.2 mm

> Outer sheath material : LSZH ; CPR Dca, EN 50575: 2014+ A1: 2016

> Cable outer diameter : 6.5 ± 0.5 mm

> Max. allowable pulling force : 1400 N

> Crush resistance : 1000/200 N/100mm

> Temperature range : transport and storage : - 40°C to + 70°C ; installation : - 40°C to + 60°C ; operation : - 40°C to + 70°C
