Aten CS1182H4C-AT-G 2P USB HDMI Single Display PP4 SecureKVM Switch with CAC
Part number:
CS1182H4C-AT-G
EAN:
4710469342035
Payment methods
Delivery methods
> Compliant with PSD PP v4.0 (Protection Profile for Peripheral Sharing Device, Version 4.0) security requirements
> Always-on chassis intrusion detection – renders the ATEN PSD PP v4.0 Secure KVM Switch series inoperable when physical tampering is detected
> Configurable Device Filtration – supports administrative configuration to filter specific USB authentication devices and USB HID devices
> Port selection via pushbuttons / Remote Port Selector (RPS) only to enhance security
Ideal solutions for your business
We find the optimal solution for your business. Our sales and presales specialists select products and services for our customers every day.
Express delivery of equipment worldwide
We guarantee on-time delivery of your equipment wherever you are. We work with global partners to ensure our logistics are optimised.
Implementation support guaranteed
We offer support in implementing solutions in your business. Our qualified engineers help you manage your infrastructure effectively.
Customer first
Our RMA experts deal with complaints and equipment replacements quickly and efficiently, so that your business can run smoothly.
Description
ATEN 2-Port USB HDMI Secure KVM Switch with CAC (PSD PP v4.0 Compliant). Keyboard port type: USB, Mouse port type: USB, Video port type: HDMI. HD type: 4K Ultra HD, Maximum resolution: 3840 x 2160 pixels, Video bandwidth: 60 Hz. Product colour: Black, Housing material: Metal. Power source: AC, Input voltage: 100 - 240 V, AC input frequency: 50 - 60 Hz. Width: 163.9 mm, Depth: 335 mm, Height: 44 mm
Multimedia
Specifications
Display
Built-in display
No
Ports & interfaces
USB 2.0 Type-B ports quantity
4
Number of computers controlled
2
Keyboard port type
USB
USB hub
Yes
Mouse port type
USB
Video port type
HDMI
Console USB ports quantity
2
Console ports
3.5mm headphone, HDMI, USB A
Console HDMI ports quantity
1
USB 2.0 Type-A hub ports quantity
1
Headphone outputs
2
HDMI ports quantity
2
RJ-11 ports quantity
1
Audio connections
Yes
Performance
HD type
4K Ultra HD
Video bandwidth
60.0000
Maximum resolution
3840 x 2160
Design
Product colour
Black
Wired remote switch
Yes
LED indicators
Yes
Housing material
Metal
Push button
Yes
Packaging data
Package volume
14724.76 cm³
Package weight
2590 g
Operational conditions
Storage temperature (T-T)
-20 - 60
Operating relative humidity (H-H)
0 - 80
Operating temperature (T-T)
0 - 50
Packaging content
Cables included
AC
Manual
Yes
Power
Input voltage
100 - 240 V
Power consumption (typical)
4.0000
AC input frequency
50 - 60 Hz
Power source
AC
Input current
1 A
Weight & dimensions
Depth
335 mm
Width
163.9 mm
Height
44 mm
Weight
1810 g
Logistics data
Master (outer) case volume
54651.514 cm³
Master (outer) case height
258 mm
Master (outer) case width
375 mm
Master (outer) case net weight
6030 g
Master (outer) case gross weight
8400 g
Master (outer) case length
565 mm
