Aten CL3116NX-ATA-DNG 16-Port Short Depth PS/2-USB VGA Single Rail WideScreen LCD KVM Switch 18.5" 1366x768 with Scandinavian keyboard
Part number:
CL3116NX-ATA-DNG
EAN:
4710469343278
Payment methods
Delivery methods
> Exclusive LED illumination light
> Integrated LCD KVM console with an 18.5'' LED-backlit widescreen LCD monitor in a single rail housing with top and bottom clearance for smooth operation in a 1U high system rack
> Cascade up to 2 levels – CL3116 controls up to 256 computers from a single console
> Keyboard and mouse emulation (PS/2 and USB) for smooth switching and simultaneously booting multiple computers even when the console focus is elsewhere
Ideal solutions for your business
We find the optimal solution for your business. Our sales and presales specialists select products and services for our customers every day.
Express delivery of equipment worldwide
We guarantee on-time delivery of your equipment wherever you are. We work with global partners to ensure our logistics are optimised.
Implementation support guaranteed
We offer support in implementing solutions in your business. Our qualified engineers help you manage your infrastructure effectively.
Customer first
Our RMA experts deal with complaints and equipment replacements quickly and efficiently, so that your business can run smoothly.
Description
ATEN CL3116NX. Display diagonal: 47 cm (18.5"), Display resolution: 1366 x 768 pixels, Display: LCD. Keyboard port type: USB, Mouse port type: USB, PS/2, Video port type: VGA. Keyboard language: Nordic, Keyboard layout: QWERTY. AC adapter input voltage: 100 - 240 V, AC adapter frequency: 50/60 Hz, Input current: 1 A. Other operating systems supported: SunOS
Multimedia
Leaflets:
Manual (PDF):
Other Digital Assets:
Specifications
Display
Response time
5 ms
Viewing angle, horizontal
170 °
Viewing angle, vertical
160 °
Display diagonal
18.5 in
Contrast ratio (typical)
1000:1
Pixel pitch
0,3 x 0,3
Supported resolutions
up to 1920 x 1200 @ 60 Hz; 1366 x 768 @ 60 Hz, DDC2B
On Screen Display (OSD)
Yes
Display
LCD
Display type
TFT
Display resolution
1366 x 768
Display brightness
450 CDM2
Ports & interfaces
I/O ports
16x SPHD
Keyboard port type
USB
Mouse port type
USB, PS/2
Video port type
VGA
VGA (D-Sub) ports quantity
1
3.5 mm (1/8-inch) in
Yes
USB 2.0 Type-A ports quantity
1
Keyboard
Keyboard layout
QWERTY
Built-in touchpad
Yes
Keyboard language
Nordic
Hot keys
Yes
System requirements
Windows operating systems supported
Yes
Mac operating systems supported
Yes
Linux operating systems supported
Yes
Other operating systems supported
SunOS
Operational conditions
Storage temperature (T-T)
-20 - 60
Operating temperature (T-T)
0 - 40
Packaging content
Rack mount kit
Yes
Cables included
AC, KVM
Manual
Yes
Quick installation guide
Yes
Technical details
Rack mounting
Yes
Product colour
Black
Compliance certificates
RoHS
Number of computers controlled
256
Rack capacity
1U
Maximum resolution
1920 x 1200
Operating relative humidity (H-H)
0 - 80
Hot-Plug support
Yes
LED indicators
Yes
KVM switch ports quantity
16
Plug and Play
Yes
On/off switch
Yes
Push button
Yes
Built-in KVM switch
Yes
Material
Metal, Plastic
Power
AC adapter frequency
50/60 Hz
AC adapter input voltage
100 - 240 V
AC (power) in
Yes
Input current
1 A
Weight & dimensions
Depth
480.6 mm
Width
631 mm
Height
42.8 mm
Weight
10600 g
