Intellinet 560764 Switch 10/100 8 port 8PoE ATAF
Part number:
560764
EAN:
0766623560764
£81.58
ex VAT
£97.90
inc VAT
Availability:
11-20
pcs
Order within:
15h
35min
The estimated delivery time is provided by the carriers. It allows you to determine the expected date when your order will reach you.
Delivery
Monday, 12 October 2026
£16.73
Fastest delivery
Friday, 9 October 2026
Payment methods
Delivery methods
> Provides power and data connection for up to eight PoE network devices
> Save time and money by delivering data and power via existing network cables
> 10/100 auto-sensing ports automatically detect optimal network speeds
> IEEE 802.3at/af-compliant RJ45 PoE/PoE+ output ports
> PoE power budget of 140 watts
> Supports IEEE 802.3at and IEEE 802.3af-compliant PoE devices (wireless access points, VoIP phones, IP cameras)
> Supports IEEE 802.3at/af detection and short circuit, overload and high-voltage protection
> All RJ45 ports with Auto-MDIX (auto uplink) support
> Store and forward switching architecture
> IEEE 802.3x flow control for full duplex
> Supports up to 2K MAC address entries
> 96 kBytes buffer memory
> Fanless design ideal for silent operation
> Desktop-size metal case
> Three-Year Warranty
Ideal solutions for your business
We find the optimal solution for your business. Our sales and presales specialists select products and services for our customers every day.
Express delivery of equipment worldwide
We guarantee on-time delivery of your equipment wherever you are. We work with global partners to ensure our logistics are optimised.
Implementation support guaranteed
We offer support in implementing solutions in your business. Our qualified engineers help you manage your infrastructure effectively.
Customer first
Our RMA experts deal with complaints and equipment replacements quickly and efficiently, so that your business can run smoothly.
Description
Intellinet 8-Port Fast Ethernet PoE+ Switch, 8 x PoE ports, IEEE 802.3at/af Power-over-Ethernet (PoE+/PoE), Endspan, Desktop, Box. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 2048 entries, Switching capacity: 1.6 Gbit/s. Networking standards: IEEE 802.1af, IEEE 802.3, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x. Power connector: DC-in jack. Power over Ethernet (PoE)
Multimedia
Leaflets:
Manual (PDF):
Specifications
Management features
Switch type
Unmanaged
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
8
Basic switching RJ-45 Ethernet ports type
Fast Ethernet (10/100)
Power connector
DC-in jack
Network
10G support
No
Networking standards
IEEE 802.1af, IEEE 802.3, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Copper ethernet cabling technology
100BASE-TX, 10BASE-T
Flow control support
Yes
Full duplex
Yes
Auto MDI/MDI-X
Yes
Design
Product colour
Black
LED indicators
Activity, Link, PoE, Power
Housing material
Metal
Certification
FCC Class A, CE
Packaging data
Cables included
AC
Manual
Yes
Operational conditions
Storage temperature (T-T)
-20 - 70
Operating relative humidity (H-H)
10 - 90
Operating temperature (T-T)
0 - 40
Packaging content
Cables included
AC
Manual
Yes
Certificates
Certification
FCC Class A, CE
Data transmission
Forwarding rate
0.1488 Mpps
Switching capacity
1.6 Gbit/s
MAC address table
2048 entries
Store-and-forward
Yes
Power
Power consumption (max)
150.0000
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Weight & dimensions
Depth
179 mm
Width
280 mm
Height
44 mm
Weight
1500 g
Logistics data
Harmonized System (HS) code
85176990
SKU:
1284439
