Workstation TS P520 W2275 W10WS
Part number:
30BE00DHUK
EAN:
0195042238020
Please contact us by phone or e-mail in order to determine the details.
Payment methods
Delivery methods
> Intel Xeon W-2275 (14C/28T, 3.3/4.6GHz, 19.25MB)
> 2x 8GB RDIMM DDR4-2933 ECC
> 1x 512GB SSD M.2 PCIe NVMe Opal
> Windows 10 Pro 64 for Workstations
List of suggested product substitutes:
Availability:
ex VAT
inc VAT
Recommended accessories:
Availability:
ex VAT
inc VAT
Ideal solutions for your business
We find the optimal solution for your business. Our sales and presales specialists select products and services for our customers every day.
Express delivery of equipment worldwide
We guarantee on-time delivery of your equipment wherever you are. We work with global partners to ensure our logistics are optimised.
Implementation support guaranteed
We offer support in implementing solutions in your business. Our qualified engineers help you manage your infrastructure effectively.
Customer first
Our RMA experts deal with complaints and equipment replacements quickly and efficiently, so that your business can run smoothly.
Description
Lenovo ThinkStation P520. Processor frequency: 3.3 GHz, Processor family: Intel Xeon W, Processor model: W-2275. Internal memory: 16 GB, Internal memory type: DDR4-SDRAM, Memory clock speed: 2933 MHz. Total storage capacity: 512 GB, Storage media: SSD, Optical drive type: DVD±RW. Operating system installed: Windows 10 Pro for Workstations, Operating system architecture: 64-bit. Power supply: 900 W. Chassis type: Tower. Product type: Workstation. Product colour: Black
Multimedia
Leaflets:
Other Digital Assets:
Specifications
Display
Display included
No
Ports & interfaces
USB 2.0 ports quantity
2
Ethernet LAN (RJ-45) ports
1
DVI port
No
Headphone outputs
1
Microphone in
Yes
Combo headphone/mic port
Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
8
Line-in
Yes
Line-out
Yes
Serial ports quantity
1
PS/2 ports quantity
2
PowerShare
Yes
Number of USB ports with PowerShare support
1
Processor
Processor manufacturer
Intel
Processor family
Intel Xeon W
Processor lithography
14 nm
Processor threads
28
Processor frequency
3.3 GHz
Maximum internal memory supported by processor
1024 GB
Number of processors installed
1
Memory clock speeds supported by processor
2933
Processor model
W-2275
Processor operating modes
64-bit
Processor cache
19.25 MB
Processor boost frequency
4.6 GHz
Maximum number of PCI Express lanes
48
Processor cache type
Smart Cache
Thermal Design Power (TDP)
165.0000
Memory types supported by processor
DDR4-SDRAM
Tcase
62 °C
PCI Express slots version
3.0
Memory bandwidth supported by processor (max)
93.85 GByte/s
Processor codename
Cascade Lake
Processor cores
14
Performance
Motherboard chipset
Intel® C422
Audio chip
Realtek ALC662
Compatible processor series
Intel Xeon W
Product type
Workstation
Audio system
High Definition Audio
Trusted Platform Module (TPM)
Yes
Password protection
Yes
Market positioning
Business
Password protection type
Power on, Supervisor
Memory
ECC
Yes
Internal memory type
DDR4-SDRAM
Memory slots
8x DIMM
Memory channels
Quad-channel
Internal memory
16 GB
Memory layout (slots x size)
2 x 8 GB
Memory clock speed
2933 MHz
Maximum internal memory
512 GB
Network
Ethernet LAN data rates
10,100,1000 Mbit/s
Ethernet LAN
Yes
Bluetooth
No
Wake-on-LAN ready
Yes
Wi-Fi
No
Cabling technology
10/100/1000Base-T(X)
Keyboard
Keyboard layout
QWERTY
Storage
Total storage capacity
512 GB
SSD form factor
M.2
NVMe
Yes
Number of storage drives installed
1
Storage media
SSD
Number of SSDs installed
1
Total SSDs capacity
512 GB
SSD capacity
512 GB
SSD interface
PCI Express, nvme
Optical drive type
DVD±RW
Card reader integrated
Yes
Compatible memory cards
SD
Processor special features
Enhanced Intel SpeedStep Technology
Yes
Intel Trusted Execution Technology
Yes
Thermal Monitoring Technologies
Yes
Idle States
Yes
Intel® AES New Instructions (Intel® AES-NI)
Yes
Execute Disable Bit
Yes
Supported instruction sets
AVX, AVX 2.0, AVX-512, SSE4.2
CPU configuration (max)
1
Intel® Identity Protection Technology (Intel® IPT)
Yes
Physical Address Extension (PAE)
Yes
Intel Demand Based Switching
Yes
Physical Address Extension (PAE)
46 b
Intel Software Guard Extensions (Intel SGX)
No
Intel® Secure Key
Yes
Intel® OS Guard
Yes
Intel 64
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
Scalability
1S
Embedded options available
No
Intel TSX-NI
Yes
Intel Virtualization Technology (VT-x)
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel® Turbo Boost Technology
2.0
Processor ARK ID
198010
Processor package size
45 x 52.5 mm
Graphics
Discrete graphics card model
Not available
On-board graphics card model
Not available
On-board graphics card
No
Discrete graphics card
No
Design
Chassis type
Tower
Product colour
Black
Number of 2.5" bays
6
Number of 3.5" bays
6
Cable lock slot
Yes
Cable lock slot type
Kensington
Volume
33 l
Placement supported
Vertical
Intel® vPro™ Platform Eligibility
Yes
Audio
Audio chip
Realtek ALC662
Audio system
High Definition Audio
Operational conditions
Storage relative humidity (H-H)
10 - 90
Storage temperature (T-T)
-40 - 60
Operating altitude
-15,2 - 3048
Operating relative humidity (H-H)
20 - 80
Operating temperature (T-T)
10 - 35
Non-operating altitude
-15,2 - 12192
Expansion slots
Number of 3.5" bays
6
PCI Express x4 (Gen 3.x) slots
2
PCI Express x8 (Gen 3.x) slots
1
PCI Express x16 (Gen 3.x) slots
2
PCI slots
1
Sustainability
Sustainability certificates
ENERGY STAR, EPEAT Silver
Packaging content
Display included
No
Keyboard layout
QWERTY
Cables included
AC
Keyboard and mouse included
No
Software
Operating system architecture
64-bit
Operating system language
English
Operating system installed
Windows 10 Pro for Workstations
Certificates
Compliance certificates
RoHS
Certification
GreenGuard, ISV
Power
Power supply
900.0000
Power supply input voltage
100 - 240 V
Power supply input frequency
50 - 60 Hz
80 PLUS certification
80 PLUS Platinum
Weight & dimensions
Depth
460 mm
Width
165 mm
Height
440 mm
Weight
24000 g
